In an earlier blog post titled 'Develop location-aware, Metro style apps when your development system doesn’t have GPS', one option I presented for those wishing to develop high-precision location-based Windows Store apps is to hook up an external GPS to your computer. What I want to do now is explore this method in greater detail, and I’m creating a three-part series on doing so with a software application called GPSDirect from TurboIRC.COM Software & Research. In part one, we’ll introduce the GPSDirect sensor driver and learn how to use it. In parts two and three, we’ll look at connecting an external GPS recevier and an Android-based smart phone as a GPS provider.
Part 1: Introducing GPSDirect
For our GPS solutions we’ll make use of the GPSDirect NEMA Sensor Driver which was developed by Michael Chourdakis at TurboIRC.COM Software & Research. It takes any COM-connected GPS receiver and turns it into a Windows Location Sensor. Though this software was originally created for the Windows 7 Sensor API, it also works with the Windows 8 Location API for both Windows Store Apps and desktop applications. Both a 32-bit and 64-bit driver are provided.
- Virtual COM Port Driver is available in the Standard and PRO editions, so you can choose the optimal set of features that is perfectly suited to your needs. Standard version Virtual Serial Port Driver is designed to provide your system with an unlimited number of virtual serial port pairs that work like real hardware COM interfaces and fully.
- Before you begin the installation, verify that the download cable driver is located in your directory: drivers usb-blaster-ii. Connect the download cable to your computer’s USB port. When plugged in for the first time, a message appears stating Device driver software was not successfully installed.
Almost all general purpose GPS units are capable of emitting NMEA 0183 sentances over a serial port. NMEA stands for the National Mareine Electronics Association, and standard 0183 defines a communication protocol for marine devices such as sonar, echosounders, GPS receivers, and its predecessor, LORAN. The NMEA protocol is extremely simple, with messages transmitted in plain ASCII text in the form of 'sentances'. These devices emerged in the days when serial ports were the primary means of interacting with computer systems, and as such even modern devices with only USB connectors still provide NMEA output via a virtual COM port by embedding a USB-to-serial adapter internally. Nearly every USB-connected GPS receiver, commonly referred to as a GPS 'mouse', is really a serial port device.
This USB-based GPS receiver shows up as a virtual serial port in Windows.
Provides support for NI data acquisition and signal conditioning devices. NI-VISA Provides support for Ethernet, GPIB, serial, USB, and other types of instruments.
GPSDirect is basically a bridge solution. It's middleware that takes a GPS device connected on a virtual COM port and connects it to the Windows Location Sensor. To date, not many manufacturers provide a true sensor driver for their GPS receivers, and GPS receivers that are integrated into tablet and ultrabook platforms are still fairly rare. For those wishing to develop precision location-aware apps-- or even just use them-- GPSDirect represents the best way to make that possible when a native GPS sensor is not available on the system. The down side is that, being middleware, you have to jump through some extra hoops to use it and you can't expect to plug in your GPS receiver and have everything just work. The rest of Part 1 discusses those hoops in detail.
Virtual COM port (VCP) drivers cause the USB device to appear as an additional COM port available to the PC. Application software can access the USB device in the This page contains the VCP drivers currently available for FTDI devices. For D2XX Direct drivers, please click here. Download the latest drivers, firmware, and software for your HP Z640 Workstation.This is HP’s official website that will help automatically detect and download the correct drivers free of cost for your HP Computing and Printing products for Windows and Mac operating system.
Download and install GPSDirect
From the GPSDirect download page, select the 32- or 64-bit driver as is appropriate for your system. The GPSDirect download is a simple EXE file. There is no installer, nor is there a driver installation procedure (but see 'Running GPSDirect', below), however GPSDirect does unpack a few support files when it executes so I like to put it in a separate folder to keep things tidy. For this example, create a 'GPSDirect' folder inside of your Documents folder and move the executable there.
Running GPSDirect
GPSDirect is a desktop application which includes a user mode driver that installs itself upon demand. Double-click to execute the binary. Windows 8 may ask you to enable location services as shown in the screenshot below. If so, click on 'yes', since location-based applications won't work without the location service.
You will then be presented with the GPSDirect user interface window, a portion of which is shown below. Before the driver can install itself, it has to know which COM port your GPS is connected to, and at what speed it communicates. These parameters are set in the main user interface.
Note that drop-down menu for the connection speed only goes up to 19200 baud, but you can type any value in there. I have used external GPS data loggers that communicate at 115200 baud successfully with GPSDirect. In addition to COM ports, GPSDirect can also communicate with a network-connected GPS device. In this case, enter an IP address for the NMEA source and a port number in the Baud Rate/Port Number box. GPSDirect also includes a simulator mode which sets a random latitude, longitude, and altitude, and then changes them slightly every second.
Select the COM port that your GPS is attached to, provide the baud rate, and then hit 'Install' to install the driver. This step will require administrator privileges since this is the point where the driver is actually installed on your system. If this is the first time you have run GPSDirect, you will also be presented with a Windows Security dialog, asking if you want to install the sensor device. To prevent this dialog from coming up again in the future, you can check the box to always trust software from the author.
Once the driver installs, the GPSDirect driver will start showing up as a location sensor in Device Manager.
Monitoring GPSDirect
When you first run GPSDirect, meaning after you have set your port settings and hit 'Install', you may not see much output. Until your GPS device has started tracking satellites, in fact, it may not appear that GPSDirect is doing anything at all but once your receiver starts acquiring signals the display will update.
The upper right window lists the satellites that have been found by the device, showing their almanac information (satellite number, azimuth, and elevation), and the strength of the signal being received. The lower frame shows the time reported by the GPS receiver, and once a fix is obtained it will display:
- latitude and longitude in decimal degrees (X and Y)
- altitude in meters (Z)
- speed in knots
- bearing in decimal degrees
- DOP (Dilution of Precision, mathematical limits on accuracy due to the current satellite geometry)
It will also periodically print one of the NMEA sentance that was received from the device.
The GPSDirect window will contnue to update as long as the GPS receiver is on and active, though if signal reception is lost it may blank out again until satellite signals can be reaquired.
You do not need to keep this window open. You can close it using the red X (there is no 'close' button) and if you later want to monitor your device, you can simply run GPSDirect again. The driver will remain active until you explicitly uninstall it.
Stopping GPSDirect
Download Thundermax Port Devices Drivers
Stopping GPSDirect really means uninstalling the driver, and that is done with the 'Uninstall' button. When you press this, GPSDirect closes the COM port, uninstalls the driver, and exits.
Things to keep in mind
- As with any system where an external device is connected to a computer, the stability of the system is dependant on the stability of the connection. If a cable comes out, the GPS receiver powers off, or if the computer goes to sleep, GPSDirect may or may not be able to seamlessly continue. It may be necessary to explicitly uninstall the driver and reinstall to get things working again.
- COM ports do not support multiple connections. If GPSDirect is using a COM port, other software will not be able to, and visa-versa.
- Your virtual COM port will change if you move your USB-connected device between ports. Always verify in device manager that your device is attached to the port that you think it is.
Download Thunder-max Port Devices Driver
In Part 2, we'll hook up an external GPS using GPSDirect.
